Add fluid system number read to LuaFluidBox

[Erythion]

The fluid system number looks very useful to tell whether two fluidboxes are connected to each other without snaking over every pipe segment in-between. The game is already keeping track of it and showing it on the debug tooltip, why not put a getter function to the Lua object? Something like LuaFluidBox.get_system_number(index).

[boskid]

ID of a FluidSystem is not part of the game state, it is not save-loaded. If you build pipes, save the game and reload you will get different id of the fluid system. Because of that it cannot be given as it would desync. It is a value only for the purpose of debugging. Similar case is with rail block id's.

If anything, method that would accept 2 fluid boxes could return bool if they both belong to the same fluid system.

[Erythion]

That function should be enough to check for connectivity, yes. Thanks.

edit: isn't the content of a fluidbox returned from the operator [] just the fluid data? how do you get the reference for the two separate fluidboxes for the parameters, then?

[raiguard]

I could like to request that this be made part of gamestate. It would SIGNIFICANTLY reduce the complexity of my Pipe Visualizer mod.


[curiosity]

But a method to tell if two fluid boxes are connected won't?

[boskid]

OK. It is now implemented for 1.1.54.

Added LuaFluidBox::get_fluid_system_id() method.

[sparr]

my Pipe Visualizer mod.

You, sir, are a terrible tease.
