Images and input backgrounds not loading?

Post by katalyka »

hi,

I love this game, but a few months ago I changed a couple files in my Ubuntu 13.10 system while trying to fix another game, and now when I try to load Factorio... the images and the backgrounds of the text inputs and boxes dont seem to load properly.

My admission of guilt is that I'm not very experienced with Ubuntu or Linux, and I don't remember what the files were any more... but they were part of running a Steam account game, and now there seems to be some conflict T____T

here's an example of the game when it fisrt starts a new map:


I know the problem isnt with Factorio, but I'm not sure where else to go to fix this, and I'm hoping you'll have seen this problem before?

thanks,
M
katalyka
Burner Inserter
Burner Inserter
Posts: 5
Joined: Tue Nov 25, 2014 7:24 pm
Contact:

Re: Images and input backgrounds not loading?

Post by katalyka »

I updated my ubuntu 13.10 to version 14.x last night.

The image problem is still occurring. :(
katalyka
Burner Inserter
Burner Inserter
Posts: 5
Joined: Tue Nov 25, 2014 7:24 pm
Contact:

Re: Images and input backgrounds not loading?

Post by katalyka »

I tried changing the config ini per the graphics discussion in the faq section, but there was no "max size" option. I turned on multithreading, and the problem is less extreme... I can see enough to play the game, although there's still lots of missing graphics... so I'm hoping to get this problem solved.

The version I am playing is base 0.10.12. The character still looks like captain power in the old blue uniform... so maybe that's showing a clue to what the problem is?
FishSandwich
Smart Inserter
Smart Inserter
Posts: 1847
Joined: Sun Feb 23, 2014 3:37 pm
Contact:

Re: Images and input backgrounds not loading?

Post by FishSandwich »

Try upgrading to 0.11 and use bitmap caching.
katalyka
Burner Inserter
Burner Inserter
Posts: 5
Joined: Tue Nov 25, 2014 7:24 pm
Contact:

Re: Images and input backgrounds not loading?

Post by katalyka »

FishSandwich wrote:Try upgrading to 0.11 and use bitmap caching.
okay, I did upgrade to the new 0.11, and turned on bitmap caching...

The character is in the new design now, but unfortuntely the missing input backgrounds and image problem is remaining.

thanks for the suggestion anyways,
M
User avatar
cube
Former Staff
Former Staff
Posts: 1111
Joined: Tue Mar 05, 2013 8:14 pm
Contact:

Re: Images and input backgrounds not loading?

Post by cube »

The max-texture-size is not in the config file by default. add it into section [graphics] ( find a line with [graphics] on it and add a new line after it saying max-texture-size=2048 )

And just to be sure, post the log file generated before trying this fix.
katalyka
Burner Inserter
Burner Inserter
Posts: 5
Joined: Tue Nov 25, 2014 7:24 pm
Contact:

Re: Images and input backgrounds not loading?

Post by katalyka »

Yep! That fixed it completely.

My Factorio is up and running again!

THANKS, Cube and Fish for your help ^_____^

*

here's the log file, anyhoo:

0545.291277 Info AllInOne.cpp:141: 2014:12:10 15:13:18; Factorio 0.11.2
0545.535644 Info AllInOne.cpp:216: Loading mod core 0.0.0 (data.lua)
0545.556364 Info AllInOne.cpp:216: Loading mod base 0.11.2 (data.lua)
0545.841431 Info AllInOne.cpp:216: Loading mod base 0.11.2 (data-updates.lua)
0571.195657 Info AllInOne.cpp:152: Initial atlas bitmap size is 8192
0571.209564 Info AllInOne.cpp:91: Created atlas bitmap 8192x8186
0571.210532 Info AllInOne.cpp:91: Created atlas bitmap 8192x4786
0612.662993 Info AllInOne.cpp:711: Downloading https://www.factorio.com/updater/get-to ... iVersion=2
0613.409819 Info AllInOne.cpp:711: Downloading https://www.factorio.com/updater/get-av ... iVersion=2
0613.929025 Notice AllInOne.cpp:146: 0 packages available to download (experimental updates disabled).
0623.967286 Notice AllInOne.cpp:112: Loading map
0623.967508 Info AllInOne.cpp:138: Map version 0.11.2-2
0686.545501 Error AllInOne.cpp:36: Segmentation fault!
/home/therani/Desktop/factorio/bin/i386/factorio[0x8099a4f]
/home/therani/Desktop/factorio/bin/i386/factorio[0x8099a8f]
/home/therani/Desktop/factorio/bin/i386/factorio[0x816ae09]
[0xb7798400]
/usr/lib/i386-linux-gnu/libstdc++.so.6(_ZNSsC1ERKSs+0x15)[0xb746fab5]
/home/therani/Desktop/factorio/bin/i386/factorio[0x8344b3d]
/home/therani/Desktop/factorio/bin/i386/factorio[0x83a8be3]
/home/therani/Desktop/factorio/bin/i386/factorio[0x84ee2ea]
/home/therani/Desktop/factorio/bin/i386/factorio[0x856c71d]
/home/therani/Desktop/factorio/bin/i386/factorio[0x859950a]
/lib/i386-linux-gnu/libc.so.6(__libc_start_main+0xf3)[0xb71c7a83]
/home/therani/Desktop/factorio/bin/i386/factorio[0x8053831]
